STEREO TYPE
MONO TYPE
LM-HSS-3000
소음이 없는 공간에서 소리를 주변에 분산시키지 않고,
미술관 또는 박물관 같은 전시관에서 소수의 가청자에게만 명료한 소리를 전달하는 목적의 스피커!
PRODUCT TYPE
-
LM-HSS-3000 MONO
-
LM-HSS-3000 STEREO
Emitter-1EA / Amplifier(2Ch)_1SET
Emitter-2EA / Amplifier(2Ch)_1SET
ELECTRICAL PROPERTIES
-
Universal power supply
Output : 30V DC @ 1.5 Amps
AUDIO PROPERTIES
-
Frequency response
-
Input impedance
-
Input connectors
-
Emitter cable connectors
-
Max input for max output
-
THD
250 Hz – 15 kHz
10k Ohms
1 RCA style connector
2 banana style connectors
160 mVrms per channel
< 0.05 @ 75% Rated Output
SYSTEM
-
Max audio SPL output
90 dB @ 1kHz/1 Meter (single)
90 dB @ 1kHz/3 Meter (single)
ENVIRONMENTAL
-
Operating temperature
-
Storage temperature
-
Operating humidity range
-
Storage humidity range
0°C to 40°C
-20°C to 50°C
0 to 95% (non-condensing)
0 to 95% (non-condensing)
MECHANICAL
-
Emitter dimensions
-
Amplifier dimensions
-
Unit weight (two emitters)
317mm x 165mm x 25mm
165mm x 165mm x 50mm
2.7kg
