STEREO TYPE

MONO TYPE

LM-HSS-3000

소음이 없는 공간에서 소리를 주변에 분산시키지 않고,

미술관 또는 박물관 같은 전시관에서 소수의 가청자에게만 명료한 소리를 전달하는 목적의 스피커!

PRODUCT TYPE

  • LM-HSS-3000 MONO

  • LM-HSS-3000 STEREO

Emitter-1EA / Amplifier(2Ch)_1SET

Emitter-2EA / Amplifier(2Ch)_1SET

ELECTRICAL PROPERTIES

  • Universal power supply

Output : 30V DC @ 1.5 Amps

AUDIO PROPERTIES

  • Frequency response

  • Input impedance

  • Input connectors

  • Emitter cable connectors

  • Max input for max output

  • THD

250 Hz – 15 kHz

10k Ohms

1 RCA style connector

2 banana style connectors

160 mVrms per channel

< 0.05 @ 75% Rated Output

SYSTEM

  • Max audio SPL output

90 dB @ 1kHz/1 Meter (single)

90 dB @ 1kHz/3 Meter (single)

ENVIRONMENTAL

  • Operating temperature

  • Storage temperature

  • Operating humidity range

  • Storage humidity range

0°C to 40°C

-20°C to 50°C

0 to 95% (non-condensing)

0 to 95% (non-condensing)

MECHANICAL

  • Emitter dimensions

  • Amplifier dimensions

  • Unit weight (two emitters)

317mm x 165mm x 25mm​

165mm x 165mm x 50mm​

2.7kg
